A3 PLUS - OPERATING INSTRUCTION
10. Specications
Installation plan: 97042084
Technicalmanual: 97071147
Dentalunitsparepartscatalogue: 97023117
Dentalchairsparepartscatalogue: 97023117
Maximum dental unit weight: 90Kg.
Maximum dental chair weight: 115Kg.
Maximum dental chair capacity: 190Kg.
Voltage: 230V~
Frequency: 50/60Hz.
Power absorbed: 1500 W
Air connection: 1/2Gas.
Air supply pressure: 6-8bar.
Air delivery rate: 82 l/min.
Water connection:
1/2Gas.
Water supply pressure: 3-5 bar.
Water delivery rate: 10 l/min
Water usage: 2 l/min.
Water hardness: <25°f(14°d).
Drainconnection: ø40 mm.
Drainagerate: 10 l/min.
Drainductinclination: 10 mm/m.
Aspirator connection: ø40 mm.
Vacuum(minimum): 65mbar.
Vacuumdeliveryrate: 450 l/min.
Mark of approval: CE 0051
Electrical work in compliance with: IEC60364-7-710
Dentalunitpackagingdimensions: 1570 x 780 x 1325(h)
Dentalchairpackagingdimensions: 1510 x 730 x 1000(h)
Dentalunitpackagingweight: 130Kg.
Dentalchairpackagingweight: 150Kg.
FUSES
Identication Value Protection Position
Dental unit.
Fuse F2
Fuse F4
Fuse F5
FuseF6
T8A
T6,3A
T6,3A
T6,3A
230V~:Dentalunitpowersupplyline.
Secondary protection: Hydrogroup.
Secondaryprotection:Dentalunit.
Secondary protection: Operatory light.
Electrical box.
Electrical box.
Electrical box.
Electrical box.
Dental chair.
Fuse F1 T4A 230V~:Dentalchairpowersupplyline.
Electrical box.
Quick-connect
couplers.
Fuse
T2A 230V~:Electricaloutletpowersupplyline
Electrical box.
MONITOR power supply.
Fuse
T4A
21V~:MULTIMEDIApowerline. Dentalchaircardarea.
