Overview
1-4
1.1 Specifications
Form Factor
ATX
Board Size
305 mm x 202 mm
CPU
Intel Pentium II Processor
System Memory
SDRAM or Registered SDRAM, 168-pin DIMM x3,
maximum 768MB.
Second-level Cache
On the CPU card (Slot1 connector)
Chipset
Intel 82440BX AGPset
Expansion Slots
ISA x2, PCI x5 and AGP x1
Serial Port
Two serial ports UART 16C550 compatible, and the
3rd UART for IR function.
Parallel Port
One parallel port supports standard parallel port (SPP),
enhanced parallel port (EPP) or extended capabilities
port (ECP).
Floppy Interface
Floppy interface supports 3.5 inches drives with
720KB, 1.44MB or 2.88MB format or 5.25 inches
drives with 360KB, 1.2MB format
IDE Interface
Dual-channel IDE interface support maximum 4 IDE
hard disks or CDROM, mode 4 , bus master hard disk
drives and Ultra DMA/33 mode hard drives are also
supported.
USB Interface
Two USB ports supported by USB bracket, the BIOS
also supports USB driver to simulate legacy keyboard.
PS/2 Mouse
Mini-Din PS/2 mouse connector onboard.
Keyboard
Mini-Din PS/2 keyboard connector onboard.
RTC and Battery
RTC within Intel PIIX4E chipset. Lithium (CR-2032)
battery is an option, no battery is needed if power cord
is plugged.
BIOS
AWARD Plug-and-Play, 2M bit Flash ROM BIOS.
Multi-language versions supported.
