Jumper Table Summary
C-2
Selecting the CPU Voltage
This motherboard supports Pentium II (Klamath) VID function, the CPU core
voltage is automatically detected, the range is from 1.3V to 3.5V.
Clear CMOS
JP14
1-2
2-3
Clear CMOS
Normal operation (default)
Clear CMOS
Tip: If your system hangs or fails to boot because of over-
clocking, simply use <Home> key to restore to the default
setting (233MHz). By this smart design, it would be more
convenient to clear CPU frequency setting. For using this
function, you just need to press <Home> key first and then
press Power button at the same time. Note that do not
release <Home> key until POST screen appearing.
AGP Ratio
JP23
1-2
3-4
5-6
AGP Ratio
Auto (default)
2/3
1/1
APAR
JP25
1-2
2-3
APAR
Disabled
Enabled (AC Power Auto Recovery)
