Hardware Installation
2-11
2.3.7 Printer
The onboard printer connector is a 25-pin D-ty
pe connector marked
PRINTER
.
The view angle of draw
ing show
n here
is from back panel of the housing.
PRINTER
PCB
2.3.8 USB
Device
You can attach USB devices to
the USB connector. The motherboard
contains tw
o USB connectors, which are marked as
USB.
USB
PCB
35
37
