Hardware Installation
2-17
2.3.16
Sound Blaster LINK
SB-LINK
is used to connect Creative PCI sound
card. If you have a Creative PCI sound
card
installed, it is necessary to link the card to this
connector for compatibility issue under DOS
environment.
Pin
1
2
3
4
5
6
Description
GNT#
GND
NC
REQ#
GND
SIRQ#
1
2
56
SB-LINK
41
43
