Overview
1-14
1.5 System Voltage Monitoring
This motherboard implements a voltage monitoring system. As you turn on your
system, this smart design will continue to monitor your system working voltage.
If any of the system voltage is over the component's standard. There will be
alarm through application software such as Hardware Monitor utility for a
warning to user. System voltage monitoring function monitors CPU core voltage.
It is automatically implemented by BIOS and Hardware Monitor utility (the file
name is like aohw100.exe, where 100 means the version number), no hardware
installation is needed.
1.6 Fan Monitoring
There are two fan connectors, one is for CPU, the other can be a housing fan.
The fan monitoring function is implemented by connecting fan to 3-pin fan
connector CPUFAN or FAN and installing Hardware Monitor utility.
Note: You need 3-pin fan that supports SENSE
signal for fan monitoring function to work properly.
