Hardware Installation
2-20
Total Memory Size = Size of DIMM1 + Size of DIMM2 + Size of DIMM3
Following table list the recommended SDRAM combinations of DIMM:
DIMM
Data chip
Bit size
per side
Single/
Double side
Chip
count
DIMM size Recommended
1M by 16 1Mx64 x1 4 8MB Yes
1M by 16 1Mx64 x2 8 16MB Yes
2M by 8 2Mx64 x1 8 16MB Yes
2M by 8 2Mx64 x2 16 32MB Yes
4M by 16 4Mx64 x1 4 32MB Yes
4M by 16 4Mx64 x2 8 64MB Yes
8M by 8 8Mx64 x1 8 64MB Yes.
8M by 8 8Mx64 x2 16 128MB Yes.
DIMM
Data chip
Bit size
per side
Single/
Double side
Chip
count
DIMM size Recommended
2M by 32 2Mx64 x1 2 16MB Yes, but not tested.
2M by 32 2Mx64 x2 4 32MB Yes, but not tested.
Following table are possible SDRAM combinations that is NOT recommended:
DIMM
Data chip
Bit size
per side
Single/
Double side
Chip
count
DIMM size Recommended
4M by 4 4Mx64 x1 16 32MB No
4M by 4 4Mx64 x2 32 64MB No
16M by 4 16Mx64 x1 16 128MB No
For getting the best performance and stability under 100MHz or above external
clock, we strongly recommend you use PC 100 SDRAM. The PC 100 SDRAM
that AOpen had tested are listed below.
Size Vendor Model Single/Double Chip Count
16M Micron MT48LC2M8A1-08 x1 8
16M TI TMX626812BDGE-10A x1 8
16M Hyundai HY57V168010CTC-10 x1 8
32M Fujitsu 81F16822D-A10-7JF X2 16
32M Micron MT48LC2M8A1-08 x2 16
32M Hyndai HY57V168010CTC-10 x1 16
