REPLACING THE DOOR'S TEMPERED GLASS PANE
To replace the tempered glass pane, do the following operations:
• Open the front door and remove the 4 side fixing screws.
• Take the tempered glass out from the bottom side and replace it.
• Insert the new glass pane with the appropriate seals.
• Carry out the operations in reverse order to re-assemble.
REPLACING THE BAKING SOLES
To replace the baking soles, do the following operations:
• Open the door at the front and remove the front floor lock section.
• Raise the refractory plane lifting with a screw driver.
• Replace the sole and refit the locking section.
REPLACING THE HEATING ELEMENT
To replace the heating element, do the following operations:
• Remove the right side panel.
• Disconnect the power wiring of the heating element inside the prover on the right-hand side.
• Dismantle and remove the heating element.
• Carry out the operations in reverse order for the refitting of the new heating element.
ADJUSTMENT OR REPLACEMENT OF THE DOOR COMPENSTION SPRING
If the door does not stay open stretch the spring further.
To adjust the tensioning or to replace the spring does the following operations:
• Remove the right side panel.
• Adjust the tension of the spring by turning the two nuts holding the tie rod.
• Replace the spring if it breaks or loses its flexible characteristics.
• Carry out the operations in reverse order to re-assemble.
Top opening glass door
