• Peak-Hold (P HOLd):
When the Peak-Hold is enabled, the gauge will display the “peak” or maximum
pressure reading since the gauge was powered on or the Max/Min value was
reset.
NOTE 1: When the Peak-Hold feature is enabled, the icon will be
displayed in the upper left area of the display.
Options: Off or On
Enabling the Peak-Hold feature:
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until P HOLd is displayed.
Step 3: Press to access the Peak-Hold setting options.
Step 4: Press or to toggle between OFF and ON.
Step 5: Press to apply the displayed setting and return to main setup menu.
NOTE 2: The peak value can be reset by pressing
MODE
ENTR
ENTR
