Full-Scale Range Adjust (RANGE):
Allows the user to adjust the reading at full-scale pressure. The reading can be
adjusted by +/-10% full-scale.
NOTE: The pressure reading must be within 5% of the full-scale value in order
to make Range adjustments. For example, a 1000 psi gauge would need
to be reading between 950 psi and 1050 psi in order to adjust the Range
feature. If the reading is not within 5% of full scale, NOAdJU (No
Adjustment) will be displayed when trying to adjust the Range.
Adjusting the Full-Scale Range:
Step 1: Ensure that the pressure reading is within 5% of full-scale.
Step 2: Press to enter the main setup menu.
Step 3: Press or to cycle through the options until AdVSET is
displayed.
Step 4: Press to access the Advanced Settings menu.
Step 5: Press or to cycle through the options until RANGE is displayed.
Step 6: Press to enter the Range adjust mode.
Step 7: Press to increase the reading, or press to decrease the reading.
Step 8: Press to accept the adjusted reading and return to the advanced
setup menu.
Step 9: To exit the Advanced Setup menu, press or until EXIT is
displayed and press to exit to the main setup menu.
MODE
ENTR
ENTR
ENTR
MODE
