• Communications (COMM):
Used to congure RS-485 Modbus communications settings (on models
equipped).
NOTE: The PG10 can function only as a slave device.
Baud Rate (bAUd R):
Sets the baud rate for the RS-485 communications. Options are 2400, 9600,
19200, 33400
Setting the Baud Rate:
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until COMM is
displayed.
Step 3: Press to access the Communications settings menu.
Step 4: Press or to cycle through the options until bAUd R is displayed.
Step 5: Press to access the Baud Rate setting.
Step 6: Press or to cycle through the baud rate settings.
Step 7: Press to accept the settings and return to the Communication
settings menu
MODE
ENTR
ENTR
ENTR
