Fast Calibration (CALIBR):
Allows the user to perform a fast calibration of the zero and span.
NOTE: Both zero pressure and full-scale pressure must be applied to the gauge
in order to complete the quick calibration process.
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the menu options until AdVSET is
displayed.
Step 3: Press to enter the Advanced Settings menu.
Step 4: Press or to cycle through the options until CALIBR is
displayed.
Step 5: Press to access the CALIBR mode. The gauge will display the
word ZERO, prompting the user to perform the zero pressure quick
calibration.
Step 6: Ensure no pressure is applied to the gauge. Press to zero the gauge.
The gauge will then display the word SPAN, prompting the user to
perform the full-scale pressure quick calibration.
Step 7: Apply full pressure to the gauge and press to complete the quick
calibration and return to advanced setup menu.
Step 9: To exit the advanced setup menu, press or until EXIT is
displayed and press to exit to the main setup menu.
MODE
ENTR
ENTR
ENTR
ENTR
