• OUTPUT:
Used to congure any optional gauges outputs, such as an analog signal or trip
point relays.
Analog Low (AL SET) & Analog High (AH SET) Setpoints:
Allows the user to dene the reading values associated with the Low Analog
signal (i.e. 4mA or 0V) and the High Analog signal (i.e. 20mA, 2V or 5V).
NOTE: The analog setpoints must be entered using the gauge’s base unit of
measure (typically PSI).
Setting the Analog Signal Span:
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until OUTPUT is
displayed.
Step 3: Press to access the Output Settings menu.
Step 4: Press or to cycle through the options until AL SET is displayed.
Step 5: Press to access the Analog Low setpoint value. A 5-digit number
will appear with the rst digit ashing.
Step 6: Press or to change the value of the rst ashing digit.
Step 7: Press to accept the value of the ashing digit and advance to the
next digit......repeat steps 6 and 7 until the desired Analog Low reading
is fully entered.
Step 8: Press to reenter the Output Settings menu.
Step 9: Press or to cycle through the options until AH SET is displayed.
Step 10: Repeat Steps 5-7 to enter the Analog High setpoint value.
Step 11: To exit the output menu, press or until EXIT is displayed and
press to exit to the main setup menu.
MODE
ENTR
ENTR
ENTR
ENTR
ENTR
