PG10 Rev. B2, 8/16
6
Automation Products Group, Inc.
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
• Operating Modes:
The PG10 has 4 standard operating modes to choose from:
Mode 000: Full Access
- Provides access to all menu settings. If no buttons are pushed for 1 minute,
the gauge will revert back to Mode 003 (factory default).
Mode 002: Limited Access
- Menu is locked.
- zeros the reading (press and hold for 3 seconds).
- or cycles between the Max and Min readings.
- On/Off functions only on battery powered gauges.
Mode 003: Factory Default
- Full access except Full Scale Calibration is locked.
Mode 005: Locked Access
- All buttons locked except will power on/off battery powered gauges.
Accessing the Operating Mode Setting:
Step 1: Simultaneously press and hold and for approximately
3 seconds. This will bring up the 3 digit mode number.
Step 2: Enter the desired mode number (see Operating Modes above) by
using or to change the value of the ashing digit, and
to accept the value and advance to the next digit.
MODE
ENTR
ENTR
ENTR
MODE
MODE
