Logging Control Menu (LOG):
Used to enable/disable datalogging, and to clear all logged records.
Setting the Logging Type (continuous or event):
The PG10 can be set to continuously log readings or to only log readings based
on the Trip Relay status.
NOTE 1: Gauges not equipped with relay outputs will still use the Trip Relay
settings to dene the pressure range(s) for the event logging (see pages 30-32
programming details).
NOTE 2: Whenever the PG10 is logging, whether in continuous or event mode,
the interval between logged readings is determined by the Logging Sample Rate
setting (see page 20).
Enabling Continuous or Event Logging
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until dATLOG is
displayed.
Step 3: Press to enter the Datalogging menu.
Step 4: Press or to cycle through the options until LOG is displayed.
Step 5: Press to access the Logging Control options.
Step 6: Press or to cycle through the setting options until CONTIN or
EVENT is displayed.
Step 7: Press to enable logging and return to logging control menu.
MODE
ENTR
ENTR
ENTR
