E6 49 DTR.APC.APR.ALW.03(ENG)
10.2.9. Configuration of the APR-2000YALW smart level probes
10.2.10. Configuration of the APR- 2000ALW transmitters for the flow measurements with
the orifice plate.
It is important to proper placement of the transmitter depending on the type of measured medium, otherwise it
may negative impact on the measurement.
Mounting diagram for liquid and steam flow:
Mechanical installation
On the flange of the tank
Upper equalization hole
Lower
equalization hole
.
Diaphragm
seal unit
