Page #18 background image
18 | Ensemble Quick Start Guide
To Get Sound In
Ensemble is equipped with eight premium-quality Advanced Stepped Gain microphone preamps
andfourinstrumentinputsontherearpanel,aswellastwoguitarinputsonthefrontpanel.
Connect to one of the two Hi-Z guitar
inputs on the front panel.
Connect a microphone or line level input
to any of the eight XLR inputs on Ensemble
Thunderbolt’s rear panel.
Connect a high impedance (Hi-Z) instrument
such as a keyboard or guitar with a 1/4”
cable to one of the combi connectors on
the rear panel.
