Apogee ensemble Quick Start Guide

6 | Ensemble Quick Start Guide
Ensemble Product Tour
Guitar Inputs
(11-12)
Input Select
Buttons
Input
Controller Knob
OLED
Displays
Output
Controller Knob
Headphones 1&2
Controller Knobs
Guitar Outputs
(11-12)
Assignable
Buttons
Headphones 1&2
Output Jacks
Built-In Mic
(Mono 9-10)
Power
Button
Inputs 1-4
Combi Jacks XLR Mic/Line
1/4” Hi-Z Instrument
Inputs 5-8
XLR Mic/Line
Optical
ADAT/SMUX/SPDIF
Coaxial
S/PDIF
Digital Audio I/O
BNC
Word Clock
IEC
Power
Monitor Out
1/4” TRS
Line Out 1-2
Analog Out
D-Sub Balanced
Line Out 3-10
Analog Inserts
Ch 1-2 Send/Return
1/4” TRS
Serial
Number
Thunderbolt™2
Front Panel
Rear Panel

Apogee ensemble Specifications

General

Type	Audio Interface
Simultaneous Channels	36
Phantom Power	Yes
Word Clock	Yes
Bit Depth	24-bit
Digital Inputs	ADAT, S/PDIF
Digital Outputs	ADAT, S/PDIF
Connectivity	FireWire
Inputs	8 analog
Outputs	8 analog
