17 6 Appendix A Icon and Port Reference
System Status Icons (Detailed)
The following icons are shown after further inspection of observed client computer
status indicators.
Service Icon Status
CPU Usage
Usage is at 60% or less
Usage is between 60% to 85%
Usage is at 85% or higher
No status information is
available
DIsk Usage
Usage is at 90% or less
Usage is between 90% and 95%
Usage is at 95% or higher
No status information is
available
Free Memory
Less than 80% used
Between 80% and 95% used
Over 95% used
No status information is
available
