Applus Technologies, Inc. Smog DADdy User Manual VER 8.2 Page 5 of 55
Hardware Descriptions
Item
Description
Purpose
1
Wired Smog
DADdy
OR
Wireless Smog
DADdy
USB enabled Data Acquisition
Device (DAD)
Bosch P/N 573926
Bluetooth enabled Data
Acquisition Device (DAD)
Bosch P/N 573927
Provides a USB interface between the test
vehicle and the computer.
Provides a wireless interface between the
test vehicle and the computer.
2
DLC Cable
(OBDII)
Wired units
16 ft. Data Link Connector
(DLC) cable. Connections:
 OBDII - male
 Computer – female
Bosch P/N 573924
Connects a wired Smog DADdy to the test
vehicle.
3
DLC Cable
(OBDII)
Wireless units
4 ft. Data Link Connector
(DLC) cable. Connections:
 OBDII - male
 Computer – female
Bosch P/N 573922
Connects a wireless Smog DADdy to the test
vehicle.
4
USB Cable
3.3 ft. USB Mini.
Connections:
 Computer - female
 Smog DADdy – female
Bosch P/N 573920
Connects a wired or wireless Smog DADdy to
the computer.
5
Self-Test Cable
1 ft. Self-Test. Connections:
 DLC cable - female
 Smog DADdy – female
Bosch P/N 573925
Tests the integrity of Smog DADdy and
vehicle DLC cable.
6
Alternate
Ground Cable
20 ft. Alternate Grounding
 Battery Clamp
 1/8” Phono Plug
Bosch P/N 573921
Provides an electrical ground for
communication when a ground pin is not
present on the test vehicle’s DLC (Pin 4 or 5)
7
Vehicle
Charging
Adapter
Wireless units
Vehicle Charger (Cigarette
Lighter) to USB Female
Converter
 Input voltage 12-24 DC
 Output voltage 5DC –
5%
Bosch P/N 573923
Provides an alternate power source when
vehicle does not have voltage on PIN 16
