Do not replace the power supply cord with an improperly
rated cord. For North American: A UL listed and CSA
labeled power cord must be used with the instrument in the
United States and Canada. The power cord must include a NEMA5-15 style male
plug, SVT or SJT cord sets, and be rated for at least 125VAC, 10A, number 16
gauge (or 125VAC, 15A, number 14 gauge) wire or larger, and the length of the
cord does not exceed 2 m must be used. For European: A certified power supply
cord not lighter than light PVC sheathed flexible cord according to IEC 60227,
designation H03 VV-F or H03 VVH2-F (for equipment mass not exceeding 3 kg),
or H05 VV-F or H05 VVH2-F2 (for equipment mass exceeding 3 kg), and be
rated for at least 3G 0.75 mm² (for rated current up to 10 A) or 3G 1.0mm² (for
rated current over 10 A up to 16 A) wire or larger, and the length of the cord does
not exceed 2 m must be used.
360XAC Power Cable Considerations
The 360XAC can be powered with several different input power configurations.
Refer to the diagram below for connecting a single phase, 3 phase wye, and 3
phase delta power source to the instrument:
L1
L2
L3
N1
N2
N3
L N
1P2W
L1
N1
L2 N2
L3
N3
A
B
C
3P3W
L1
N1
L2
N2
L3
N3
A
BC
N
3P4W
AC IN
L3
G
N2
AC IN
L2
G
N3
PFC1
360XAC
N1
L1
AC IN
G
PFC3
PFC2
L
1P2W
N3
L1
G N2
L2L3
G N
N1
N3
C
L3
G
3P3W
L1
N1
L2
N2
BAG
L2
N
L3
N1
B
G
N2
L1
N3
A
G
3P4W
C
Power System Rear Panel
