APT 340XAC User Manual

21
MEASUREMENT
DC Cont.
310XAC
320XAC
340XAC
360XAC
H
1.00 A - 13.00 A
2.00 A - 26.00 A
0.05 A - 52.00 A
0.05 A - 78.00 A
Resolution
L
0.001 A
H
0.01 A
Accuracy
L
± (1% of reading + 5 counts)
H
± (1% of reading + 5 counts)
Power
Range
L
0.0 W - 120.0 W
0.0 W - 240.0 W
x
x
H
100 W - 1300 W
200 W - 2600 W
0 W - 5200 W
0 W - 7800 W
Resolution
L
0.1 W
x
x
H
1 W
Accuracy
L
± (2% of reading + 5 counts)
x
x
H
± (2% of reading + 5 counts)
TEST SETTING PARAMETERS
310XAC
320XAC
340XAC
360XAC
Memory
Range 1 - 50 Locations
Memory Cycle
0 -9999, 0 = Cont., 1 = OFF
Step
AC
Range 1 - 9
DC
Range 1-5
Step Cycle
0 - 9999, 0 = Cont., 1 = OFF
Voltage Output
AC, DC
Voltage
Range
AC
5.0 - 300.0 V High/Auto Mode
5.0 - 300.0
DC
5.0 - 420.0 V High/Low Range
5.0 - 420.0
Resolution
0.1 V
Accuracy
± (1% of reading + 2 counts)
± (1% of reading + 5 counts) > 5 V
Voltage Hi-Lmt
AC
5.0 V - 300 V
5.0 V - 300 V
DC
5.0 V - 420 V
5.0 V - 420 V
Voltage Lo-Lmt
AC
5.0 V - 300 V
5.0 V - 300 V
DC
5.0 V - 420 V
5.0 V - 420 V
Frequency Hi-Lmt
Range
40.0 - 1000 Hz
Frequency Lo-Lmt
Range
40.0 - 1000 Hz
Frequency
Resolution
0.1 Hz @ 40.0 - 99.9 Hz, 1 Hz @ 100 - 1000 Hz
Accuracy
±0.03%
Current (rms) Hi-Lmt
Range
AC
0.005 A – 9.2 A,
0 = OFF
0.005 A - 18.4
A, 0 = OFF
0.05 A - 36.8 A,
0 = OFF
0.05 A - 55.2 A, 0
0 = OFF
DC
0.01 A - 4.60 A
0.01 A - 9.60 A
0.10 A - 18.40 A
0.10 A - 27.6 A
Current (rms) Lo-Lmt
AC
0.005 A - 9.2 A
0.005 A - 18.4 A
0.05 A - 36.8 A
0.05 A - 55.2 A
DC
0.01 A - 4.60 A
0.01 A - 9.60 A
0.10 A - 18.40 A
0.10 A - 27.6 A
Current (rms)
Resolution
0.01 Amp
Accuracy
± (2.0% of setting + 2 counts)
Current (peak) Hi-
Lmt
0.0 A- 38.0 A,
0 = OFF
0.0 A - 76.0 A,
0 = OFF
0.0 A - 152.0 A,
0 = OFF
0.0A - 228 A,
0 = OFF
Current (peak) Lo-
Lmt
0.0 A- 38.0 A
0.0 A - 76.0 A
0.0 A - 152.0 A
0.0A - 228 A
Power Hi-Lmt
0.0 W - 1000 W,
0 = OFF
0.0 W - 2000 W,
0 = OFF
0 W - 4000 W,
0 = OFF
0 W - 6000 W,
0 = OFF

APT 340XAC Specifications

General

Brand	APT
Model	340XAC
Category	AC Power Distribution
Language	English
