Ensuring the hose washer is in position; attach the hose to the wall
outlet. Run the shower for a few seconds to clear any debris that may be
present (wall outlet installation instructions - page 21).
9
Pass the shower hose through the gel hanger and ensuring the hose
washers are in the correct position, depress the anti-swivel locking
button on the handset and secure the handset to the hose. Place the
handset into the handset holder.
INSTALLATION ADJUSTABLE RAIL KIT
SQUARE
(Refer to page 25 for round kit)
1
Prepare two fixing points at 700 - 740mm
using the fixings provided (if suitable).
N.B. Ensure that the hose will not be over
extended when the slider is at its highest
position.
2
Insert a screwdriver or similar tool
inside the slot at the back of the rail end
assembly to gently prise the rail end
covers from the brackets, taking care not
to damage the chrome plating.
