INSTALLATION WASTE PIPE EXTENSION
KIT WHERE REQUIRED
IMPORTANT:
If required for larger baths, a 900mm waste pipe
conversion kit is available from the Aqualisa Customer
Service department, part number 910064. Please contact
our Customer Service Department on 01959 560010.
1
Unscrew the clamping nut and remove the waste pipe from the
waste assembly.
2
Remove the clamping nut and sealing washer from the waste pipe
and set aside.
3
Carefully cut down the length of the waste pipe, and disconnect
from the outlet assembly, ensuring not to damage the outlet.
4
To reassemble, push the longer waste pipe into position over the
outlet, and secure it in place using a jubilee clip (not supplied).
N.B. The waste pipe may need to be softened by running it under hot
water, to ensure it slides over the outlet.
