30
5
Connect the bath waste to a suitable trap (not supplied).
6
Oer the outlet body assembly into position at the rear of the bath
ensuring the rubber washer is correctly aligned between the outlet
body assembly and bath wall.
7
Ensuring the rubber washer is correctly
aligned, pass the overflow filler outlet
through the bath and secure to the body
assembly.
8
Remove the relevant inlet blanking plug and attach the flexible hose
to the blended inlet connection.
IMPORTANT:
PTFE thread tape or similar MUST be used to guarantee a
watertight seal.
9
Connect the flexible hose to the blended supply pipe ensuring a
suitable non-restrictive double check valve (not supplied) is fitted in
line with current Water Supply Regulations.
