23
UK
Place the wall fixing plate into position and mark and prepare the
fixing points using the fixings provided, if suitable. Secure the wall
fixing bracket to the wall using the screws provided, if suitable.
Ensuring the fixed head washer is in place, carefully screw the
shower head to the fixed riser arm taking care not to damage the
plated surface. Carefully tighten the shower head with a suitable
tool taking care not to overtighten.
Pass the bottom of the riser rail through the handset holder while
keeping the slider levers depressed. Ensure the handset holder
is in the correct orientation.
Re-position the riser rail assembly onto the mixer valve outlet.
Tighten the fixing nut using a suitable tool, taking care not to
overtighten.
11
13
12
14
