Page 10
Steps & Tips:
- Remove assemblies from box.
- Hang level controls from hooks inside tank.
- Connect level controls as required.
E.S.P.S ENVIROMENTALLY SEALED PRESSURE SWITCH
- Quick connect Electrical Plug
- Slide down Guide rail (guide rail option)
- Hang E.S.P.S from hook (free standing option)
Figure 11: Level Control Options
Level Controls
E.S.P.S OPTIONPRESSURE TRANSDUCER
LEVEL CONTROL
FLOAT SWITCH OPTION
STEP 5.
—
