5.5 Replacement of electrode and nozzle
! WARINING BEWARE OF ELECTRIC SHOCK!
When the phenomena below occur, the electrode and nozzle should be replaced.
Otherwise, there will be strong arc in the nozzle, which will break down the electrode and
the nozzle, or even burn the torch. Nozzles of different models are different, so ensure the
nozzle is of the same model when replacing it.
1. Electrode wear＞0.06in
2. Distortion of the nozzle
3. Cutting speed declining, arc with green flame
4. Difficult in arc ignition
5. Irregular cut
Figure 19 Exploded view of cutting torch
If the accessories of cutting torch need to be replaced, please log in to the official
website: WWW.ARCCAPTAIN.COM
6.MAINTENANCE
! WARINING BEWARE OF ELECTRIC SHOCK!
NOTICE:
The power of the switching box and the cutting machine should be
shut down before daily checking (except appearance checking
without contacting the conductive body) to avoid personal injury
accidents such as electric shock and burns.
