1-2
General Specifications
Snowmobile
Identification
The Arctic Cat Snowmobile has two important identifica-
tion numbers. The Vehicle Identification Number (VIN)
is stamped into the tunnel near the right-side footrest. The
Engine Serial Number (ESN) is stamped into the crank-
case of the engine.
0726-383
These numbers are required to complete warranty claims
properly. No warranty will be allowed by Arctic Cat Inc.
if the engine serial number or VIN is removed or muti-
lated in any way.
Recommended
Gasoline and Oil
RECOMMENDED GASOLINE
The recommended gasoline to use in these snowmobiles
is 87 minimum octane regular unleaded. In many areas,
oxygenates (either ethanol or MTBE) are added to the
gasoline. Oxygenated gasolines containing up to 10%
ethanol or up to 15% MTBE are acceptable gasolines. Do
not use gasolines containing methanol.
RECOMMENDED OIL (120 cc)
The recommended oil to use is a multi-grade or single-
grade engine grade oil calibrated to the ambient tempera-
ture at which the engine is run. See the viscosity charts for
details.
GEN-0048
660 cc
Bore x Stroke 68.0 x 60.4 mm
(2.677 x 2.378 in.)
Displacement 658 cc (40.15 cu in.)
Gas Tank Capacity
(Actual)
62 l (16.5 U.S. gal.)
Gas Tank Capacity
(Rated)
57 l (15.5 U.S. gal.)
Chain Case Capacity
(w/o Reverse)
236 ml (8 fl oz)
Chain Case Capacity
(w/Reverse)
354 ml (12 fl oz)
Engine Oil Capacity 2.9 l (3 U.S. qt)
Cooling System Capacity 3.8 l (1 U.S. gal.)
120 cc
Bore x Stroke 60 x 42 mm
(2.36 x 1.7 in.)
Displacement 119 cc (7.3 cu in.)
Gas Tank Capacity
(Actual)
1.7 l (0.46 U.S. gal.)
Gas Tank Capacity
(Rated)
1.5 l (0.40 U.S. gal.)
Engine Oil Capacity 550 ml (18.6 fl oz)
! CAUTION
Do not use white gas or gasoline containing
methanol. Only Arctic Cat approved gasoline
additives should be used.
! CAUTION
Any oil used in place of the recommended oil
may cause serious damage.
Multi-Grade
