Release the lifting apparatus.
拆除吊装绳索等。
With the spirit level, check that all the rotary discs (5.11 and 5.12 Fig. 5A, 5D) that
support the rotary insulators (1.1 Fig. 1A, 1B) are horizontal in the two perpendicular
directions. If needed shim with the C-washers on the bolts, between the support
structure and the brackets of the bases, until the bases are adequately level.
用水平仪检查支承旋转绝缘子（图 1A，1B 之 1.1）的所有旋转盘（图 5A，5D 之 5.11
和 5.12），要求这些表面在互相垂直的两个方向都是水平的。必要时，可在螺栓上，
底座的支承结构和支架间，借助 C 形垫片适当地为底座找平。
Before fastening finally the base to the structure, check also that:
将底座最终固定于支架前，还要检查：
• the base is aligned with the support structure;
底座和支架结构对准；
• the base is level;
底座保持水平；
• during final fastening no deformation has taken place altering the adjustments
already carried out. If needed repeat the operations above.
最终紧固时，是否发生变形，从而改变了已取得的调整结果。必要时，重复上述
调整。
6.4.2 Rotary insulators (Fig. 1A, 1B, 2D, 5A, 5B, 5D, 5E)
旋转绝缘子（图 1A, 1B, 2D, 5A, 5B, 5D, 5E ）
Turn the rotary discs (5.11 and 5.12 Fig. 5A, 5D) by hand and set the disconnector to
the CLOSED position as shown in figure 5.
用手转动旋转盘（图 5A，5D 之 5.11 和 5.12）并按图 5 所示将隔离开关置于合闸位置
。
Remove the stop plate (5.14 Fig. 5A, 5D) installed on the rotary disc (5.11 Fig. 5A,
5D) on the side of the female arm and the interlocking plate (5.23 Fig. 5A, 5D)
installed on the rotary disc (5.12 Fig. 5A, 5D) on the side of the male arm; take notice
of their positions and mark them.
取下安装在雌刀臂一侧转动盘（图 5A，5D 之 5.11）上的限位板（图 5A，5D 之 5.14
）和安装在雄刀臂一侧转动盘（图 5A，5D 之 5.12）上的互锁板（图 5A，5D 之 5.23)
；注意其位置并做上记号。
Lift the insulators (1.1 Fig. 1A, 1B) as shown in figure A and lay them down slowly
onto the rotary discs.
如图 A 所示提起绝缘子（图 1A，1B 之 1.1）并把它缓慢地向下放到转动盘上。 The
position of each insulator is correct when the holes of the upper flange are at 45° in
relation to the longitudinal axis of the base (Fig. 2D).
当上法兰上的孔相对于底座（图 2D)纵轴成 45°时，各绝缘子的位置就是正确的。
Install again on the rotary disc (5.11 Fig. 5A, 5D) on the side of the female arm the
stop plate (5.14 Fig. 5A, 5D) and on the rotary disc (5.12 Fig. 5A, 5D) on the side of
the male arm the interlocking plate (5.23 Fig. 5A, 5D) previously removed, do not
tighten them finally.
