9. DISASSEMBLING THE SWITCHGEAR AND REPLACEMENT OF
MAIN PARTS
隔离开关的拆卸及主要部件的更换
Danger
危险
9.1 DISASSEMBLING THE DISCONNECTOR
隔离开关的拆卸
WARNING: BEFORE CARRYING OUT ANY OF THE FOLLOWING OPERATIONS, MAKE
SURE THAT:
警告！在进行下列任何操作之前，确保：
a) the disconnector is in the OPEN position;
隔离开关处于“开”位；
b) both the incoming and outgoing conductors are visibly connected to the earth;
所有进线和出线都已明显接地；
c) the drive is disconnected from all low-voltage conductors.
操作机构已与所有低压导线断开。
9.1.1 Disconnection
断开
Disconnect all high-voltage conductors from the line terminals.
断开接线柱上的所有高压导线。
Disconnect all low-voltage conductors from the drive.
断开操作机构的所有低压导线。
9.1.2 Disassembly
拆卸
With the same tools used during the installation of the disconnector, but in a
sequence reverse to that of Chapter 6, remove the parts in the following sequence:
采用与安装时相同的工具，以与第 6 章中所述相反的步骤，按下列顺序拆除部件：
S2DA DISCONNECTORS:
S2DA
隔离开关：
• vertical drive shaft and drive of the disconnector;
隔离开关的垂直驱动轴和驱动机构；
• live parts: arms with male contacts;
通流部分：带雄触头的刀臂；
• live parts: arms with female contacts;
通流部分：带雌触头的刀臂；
