4
EN
HOW TO INSTALL BATTERIES
● Remove trhe lid in the rear part of the
remote control unit.
TEMPERATURE SENSOR SELECTOR
●
Under normal conditions the room temperature is
detected and checked by the temperature sensor placed
in the remote controller (I FEEL
icon displayed ).This
function is designed to provide a comfortable room
temperature by transmitting the temperature control
command from the location next to you. When using this
function, the remote, control should always be pointed
at the air conditioner, therefore it should be placed in
a position in which it is visible by the indoor unit (for
example, do not put it in a drawer).
●
It is possible to disable the remote controller room sensor
by pressing and holding the FAN/I FEEL button. In
this case the I FEEL icon on the remote controller display
lights off and only the sensor placed in the air conditioner
becomes active.
USING THE REMOTE CONTROL UNIT
●
Insert two AAA alkaline batteries of
1,5 V-DC making sure that point in
the direction marked in the battery
compartment.
●
Set the clock (see procedure on page
6).
Remote controller is now ready for
operation.
●
The batteries last average more than
six months, anyway it depends on how much you use
the remote control unit.
Remove the batteries if you do not use the remote
control unit for more than one month.
Replace the batteries when the battery symbol appears
on the remote control ( )
●
The batteries of the remote control contain polluted
substances. Exhausted batteries must be disposed
according to the laws in force.
OPERATION WITH THE REMOTE CONTROL UNIT
When using the remote control unit, always point the unit
transmitter head directly at the air conditioner receiver.
The remote control unit transmits signals to the indoor
unit each time you press a key and at any temperature
change detected by the internal sensor. In case of
troubles (low batteries, remote control placed in
a position not visible by the indoor unit,...) room
temperature control is automatically switched to the
sensor of the indoor unit. In this case, the temperature
around the remote control unit may differ from the
temperature detected in the air conditioner position.
NOTE
SAFETY INSTRUCTIONS
●
Read this booklet carefully before using this air
conditioner. If you still have any difficulties or
problems, consult your dealer for help.
●
This air conditioner is designed to give you
comfortable room conditions. Use this only for its
intended purpose as described in this Instruction
Manual.
●
Never use or store gasoline or other flammable vapor or
liquid near the air conditioner. It is very dangerous.
●
Never install electrical equipment, which is not
protected with IPX1 protection (protection against
vertical water drop), under the unit.
●
The manufacturer assumes no responsabilities if the
safety regulations or local codes are not observed.
●
Never use the power main switch to start or stop the
air conditioner: always use the ON/OFF button on the
remote control unit or the selector switch on the unit.
●
Do not let children play with the air conditioner.
●
Do not cool the room too much if babies or invalids
are present.
●
This air conditioner is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the air conditioner
by a person responsible for their safety.
WARNING
CAUTION
INSTALLATION LOCATION
●
This air conditioner must be installed by qualified
installation technicians in accordance with the
installation instructions provided with the unit.
●
Do not install this air conditioner where there are
fumes or flammable gases, or in an extremely humid
space such as a green house.
●
Do not install the air conditioner where excessively
high heat-generating objects are placed.
●
Do not install the air conditioner where the
atmosphere is extremely damp or humid (e.g.
greenhouse or laundry) it could be wetted by drops
of water (i.e. in laundries).
●
To protect the air conditioner from heavy corrosion,
avoid installing the outdoor unit where salty sea
water can splash directly onto it or in sulphurous
air near a spa.
WARNING
ELETRICAL REQUIREMENTS
●
Before installation, check that the voltage of the electric
supply in your home or office is the same as the voltage
shown on the nameplate.
●
All wiring must conform to the local electrical codes.
Consult your dealer or a qualified electrician for details.
●
Each unit must be properly grounded with a ground (or
earth) wire or through the supply wiring.
●
Wiring must be done by a qualified electrician.
NOTE
ONLY IF YOU INSTALL MORE THAN ONE
INDOOR UNIT IN THE SAME ROOM
Set unit 1, 2, 3 or 4 with Remote Control (see procedure
in Installation Manual).
RESET
-
+
-
+
HOW TO REMOVE BATTERIES
• Remove the lid.
• Press the battery
toward the negative
end and lift it out by its
positive end (as shown
in the figure).
• Remove the other
battery in the same
way.
RESET
-
+
-
+
