EN
11
ADJUSTING THE AIR FLOW DIRECTION
HORIZONTAL (manual)
The horizontal air flow can be adjusted by moving the lever
to the left or right, as indicated in the following figure.
VERTICAL (with remote control unit)
Make sure that the remote control unit has been turned on.
Press
the FLAP button to select the flap function
Do not move the flap with your hands when the air
conditioner is running.
CAUTION
NOTES
●
The flap automatically closes when the unit
is off.
●
When the unit starts in heating operation,
the fan stops and the flap is in the 4 position
(if automatical oscillation is selected) until
the air being blown out of the unit begins
to warm. Once the air warms up, the flap
position and fan speed change to the
settings specified with the remote control.
• Use the FLAP button on the remote control to adjust
the position of the flap. If you move the flap by hand,
the factual flap position and the flap position on the
remote control may no longer match. If this should
happen, shut off the unit, wait for the flap to close,
and then turn on the unit again; the flap position will
now be normal again.
• Do not have the flap pointed down during cooling
operation. Condensation may begin to form around
the air vent and drip down.
CAUTION
Lever
Up
Down
Air outlet
grille
Flap
HOW TO ADJUST THE FLAP DIRECTION
Zone «A»
for cooling and dehumidifyng
Zone «B»
for heating
Set vertical vanes to the front position during COOLING/
DRY operation if humidity is high.
If the vertical vanes are set to the left-most or right-
most position, condensation will form around the air
outlet and drip off.
CAUTION
A
A
A
Fixed:
six
position
Continous
oscillations
Automatical
oscillations
35*+
9+:
:[XHU
+IU
4OMNZ
,ORZKX
:OSKX
2OMNZ
S
1
M
W
T
T
F
S
AUTO
WEEK
SET
2
3
A
