E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
6.1 Seat Post Assembly
Assembling with Shimano Di2
The Di2 battery is hidden in the seatpost:
1. Apply grease on the ribs of the internal
battery holder (SKU: 80167)
2. Place the battery between both pieces of the
internal battery holder.
3. Slide the assembly into the seatpost.
4. Route a Di2 cable down to the BB and
connect it to the battery.
5. Follow the other groupset steps to complete
the assembly.
Assembling with other groupset:
1. Apply carbon paste to the inside of the frame
(seat tube).
2. Slide the seatpost into the cavity.
Di2 only
