E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
11.1 FRAME routing – overview - etap
1. Rear brake housing must be routed UNDER the bottom bracket sleeve.
2. All housings MUST be covered by a foam liner up to the BB shell.
See page 23. (SKU: 80811).
For Di2 routing see page 25.
For mechanical routing see page 35.
