Argon 18 E-119 TRI+ - 12. FRAME ROUTING - MECHANICAL; 12.1 FRAME ROUTING - OVERVIEW - MECHANICAL

35
12.1 Frame routing – overview - Mechanical
1. The rear brake housing must be routed under the bottom bracket sleeve.
2. Both derailleur cable housings will be UNDER the bottom bracket sleeve
once installed.
3. All housings MUST be covered by a foam liner from BB shell up to the bento box.
See page 23. (SKU: 80811).
