12.3 frame routing – Mechanical
Assembling the door frame receptacle:
1. Press the door frame receptacle (SKU:
81507) into place.
2. Apply threadlocker (no. 242) to the
threads of the four M4 x 10 mm flat
head screws.
3. Hand-tighten the four screws.
