Argon 18 E-119 TRI+ - 13.5 BRAKE LEVER ASSEMBLY

44
E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
13.5 Brake Lever Assembly
1. Choose the correct handle kit for your build: mechanical (included in SKU:
81512), Di2 (included in SKU: 81513) or eTap (included in SKU: 81514)
2. Insert the right handle into the right side of the handlebar.
3. Slide it in until the hole is aligned with the hole in the handlebar. Isopropyl
alcohol can be used to slide the handle in if an air compressor isn't availlable.
4. Repeat for the left handle on the left side of the handlebar.
5. Return the handle on itself until the end of the handlebar is visible.
included with:
81514
Left Right
eTap
included with:
81513
Left Right
Di2
Included with:
81512
Mechanical
Left Right
