Argon 18 E-119 TRI+ - 13.4 BRAKE LEVER ASSEMBLY - ADAPTER FOR MECHANICAL ROUTING

43
13.4 Brake Lever Assembly - adapter for Mechanical Routing
Included with:
81512 (2X)
4
6Nm
2.5
1Nm
4
5.5Nm
4
7Nm
2
HT-1/4
5
12Nm
2
2Nm
3
3Nm
4
3Nm
8
35Nm
2.5
HT
3
HT
40Nm
4Nm
T25
T25
4
3Nm
10
HT
2.5
5
9Nm
2.5
HT-2
2.5
HT-5
2.5
2Nm
3
2.5
HTHT
3
4Nm
3
2Nm
6
10Nm
2.5
HT
4Nm6Nm
8
M3 x 12mm
1. Choose the blank mechanical adapter (included in SKU: 81512).
2. The blank mechanical adapter is reversible. It can be installed on
either brake lever.
3. Set the blank mechanical adapter on the brake lever.
4. Apply grease to the threads of the M3 x 12 mm adapter screw.
5. Hand-tighten the M3 x 12 mm screw in the shifter.
6. Repeat for the other side.
M3 x 12mm
