Argox A-2240 - Cutter Mode

A Series User’s Manual
31
Cutter Mode
Note: For cutter mode you must first install the cutter and cutter
baby board to J16 on the main board
1. Turn off the POWER switch.
2. Unscrew the two screws behind the front cover.
3. Remove the front cover.
Front Cover
Screw
A Series User’s Manual
32
4. Loose the 2 screws on the printer bottom.
5. Pull out front side of "Middle Cover" then remove it from
"Bottom".
6. Take out "Middle Cover".
Screw
