A Series User’s Manual
35
9. Reattempt the print head assembly by securing the 4 screws
and pull the front side of "Middle Cover" to put it back.
10. Screw the 2 screws on the printer bottom.
11. Unscrew the screw on the printer module.
12. Remove the tear off bar.
Tear Off Bar
A Series User’s Manual
36
13. Plug in the cutter connecter
14. Mount Cutter module, and install cutter module completely.
