7
Ribbon Supply Holder
2. Unlatch the print head module by pushing the two white release
levers on the sides toward the rear.
3. Turn over the print head module to expose the ribbon supply
holder.
Media Compartment
Release Lever
Print Head Module
8
4. Unwrap the ribbon roll pack and separate the ribbon roll and
the bare core.
5. Attach the edge of the ribbon on the bare core and wind it a
little bit onto the core.
6. Insert the ribbon roll into the supply holder. (First snap in the left
side and then the right side.)
Ribbon Roll
Bare Core
