7. Repeat the previous step until you set all
the rules you need, and click the String
tab.
8. In the String tab, there are 10 string
boxes: Insert G1-G10 chars setting. Each
box corresponds to the group you’ve
selected in the string list in the Data
Magic tab. Depending on your selection,
type the text you want in the specific
box. For example, if you’ve selected
Group1, type in the Insert G1 chars
setting box. The string box accepts up to
12 single-byte characters. When you’re
done, click OK.
9. On the Tool menu, click Export Config
(from Host), and click Export. If the data
is exported successfully, you’ll hear a long
beep.
Note The bar codes types available in
Data Magic are the same as those you’ve
turned on. For more information about
how to turn on bar codes types, see
Chapter 4.
