Reference Technical Information
1. General Specification
Specification Model G-6000
Print method Direct thermal and thermal transfer
Resolution 203 DPI ( 8 dots/mm)
Printing width Max 6.4” (164 mm), Max 6” (152mm) in cutter mode.
Printing length 1” ~ 30” (25mm ~ 762mm)
Printing speed 2~6 ips (51~152 mm/s)
Memory 2Mb DRAM, 1Mb Flash ROM
CPU type 32 bit RISC Microprocessor
Media sensor Reflective and see-though Transmissive
Display Back-lit LCD display, 2-lineX16, LED indicator X 3
Communication
interface
Centronics parallel, RS-232 serial
Maximum label
roll diameter
8 in.(203 mm) outside diameter
1.5 in. ~ 3.0 in.(38 mm ~ 76 mm) inside diameter
Media type Roll-feed, die-cut, continuous, fan-fold, ta
thermal paper or plain paper.
Label indexing Black stripe and gap
Ribbon types Wax, Wax/resin and Resin ; Coating inside
Ribbon size OD 2.5 in. (63mm)
ID 1 in. (25 mm)
Compact size W12.1” ╳ H10.2” ╳ L17.3” (W310╳ H260╳ L445 mm)
Weight 32Ibs ( 14.5kg )
Power source 110/220 VAC + 10%, 50/60 Hz
Agency listing CE, UL, CUL, FCC class A
Operating
temperature
40° ~ 100°F (4° ~ 38°C)
10~90% non condensing
Storage
temperature
-40°F ~ 140°F (-40°C ~ 60°C)
Windows driver for Win 98, 2000 ,NT and XP
Printer emulation PPLA
Optional
Accessories
♦
♦
♦
♦
♦
♦
♦
♦
Serial (RS232) cable
Dispenser
Cutter
Flash memory
Font board
Standalone KDU – ArgoKee
USB interface
Printer server – ArgoNet
( for Ethernet connection )
Note:
The font board and flash memory board cannot be
installed simultaneously.
55
56
Internal Universal Power Supply
