EN - 15
Your Ariens dealer can provide service and
adjustments to keep your unit operating at
peak efficiency. Contact an authorized engine
manufacturer’s service center for engine
service.
MAINTENANCE SCHEDULE
SERVICE PARTS
See your Ariens dealer to purchase service
parts for your unit.
SERVICE POSITION
1. Place unit on a flat, level surface.
2. Stop engine and wait for all moving parts
to stop and for hot parts to cool.
3. Drain fuel from fuel tank and fuel system.
Refer to engine manual for instructions.
4. Disconnect spark plug wire.
5. Adjust handlebar to full vertical position.
See Adjust Handlebar Height on page 13.
6. Rotate unit onto its right side. Ensure the
unit is secure and will not tip. See
Figure 15.
MAINTENANCE
CAUTION: AVOID INJURY. Read
and understand the Safety section
before proceeding.
Service Performed
Each Use
Every 5 hrs.
Every 25 hrs.
Every 100 hrs.
Check Operator Presence
Control
•
Check Wheel Drive Control •
Check Grass Bag •
Clean Unit •
Check Engine Oil * •
Check Cooling Fins * •
Check Mower Blade •
Check Drive Belt •
Check Fasteners •
Wash Deck •
Clean Grass Bag •
Check Air Filter * •
Change Engine Oil *
General Lubrication •
Check OPC Lever Cable
Adjustment
•
Check Spark Plug *
Clean Engine Cooling Fins * •
Check Muffler •
* Refer to engine manual for instructions.
Description Part No.
Air Cleaner (Models 911607,
911609, 911608)
21575020
Air Filter 21575023
Air Filter Foam Pre-Cleaner
(Model 911614)
21575024
Replacement Blade Kit 71107500
Laser Edge Blade Kit 71107600
Dual Blade Kit 71107700
Dual Blade Upgrade Kit
(Models 911607, 911609,
911608)
71107800
Transmission Belt (Model
911608)
07200923
Transmission Belt (Models
911609, 911614)
07200924
Grass Collector Bag 30122000
Fuel Stabilizer – 118 mL
(4 oz)
04730400
CAUTION: AVOID INJURY.
Before placing unit in service
position, drain fuel from tank and
fuel system. (Refer to engine
manual for instructions).
Make sure unit is secure and will
not tip.
