EN - 8
1. Engine Key
2. Primer Bulb
3. Fuel Tank and Cap
4. Fuel Valve
5. Electric Start Button
6. Choke Control Knob
7. Oil Fill / Dipstick
8. Oil Drain
9. Recoil Starter Handle
10. Speed Selector Lever
11. Auger
12. Impeller
13. Shear Bolt (2)
14. Attachment Clutch Lever
15. Traction Drive Clutch Lever
16. Height Adjustment Lever (Model 920028)
17. Discharge Chute Rotation Lever
18. Discharge Chute Deflector Lever
19. Scraper Blade
20. Skid Shoe (2)
21. Axle Lock Pin (2) (Models 920025,
920026, 920027)
22. Snow Clean-out Tool
23. Discharge Chute
24. Discharge Chute Deflector
25. Belt Cover
26. Gearcase
CONTROLS & FEATURES
18
25
12
21
20
14
22
19
24
10
17
11
13
6
5
9
8
1
2
4
15
16
23
Figure 3
26
7
3
1
