EN - 14
MAINTENANCE SCHEDULE
SERVICE PARTS
See your Ariens dealer to purchase service
parts for your unit.
CHECK DUAL HANDLE
INTERLOCK
1. Stop engine.
2. Engage attachment clutch and then the
traction drive clutch.
3. Release the attachment clutch lever. The
attachment clutch should stay engaged
until the traction drive clutch lever is
released.
IMPORTANT: If dual handle interlock does
not operate correctly, adjust or repair as
directed in the service guide for your unit.
CHECK FASTENERS
Check for loose hardware.
CHECK CLUTCH CABLE
ADJUSTMENTS
Auger / impeller must stop within 5 seconds
when attachment clutch lever is released.
Wheels must stop quickly when traction drive
clutch lever is released.
If clutches do not engage or disengage
correctly, see Adjust Attachment Clutch &
Brake on page 20 or Adjust Traction Drive
Clutch on page 22. Refer to the service guide
for your unit for more information about clutch
repairs.
CHECK TIRE PRESSURE
Models 920025, 920026, 920027
Keep tires inflated to pressure listed on tire
sidewall.
CHECK ENGINE OIL
NOTICE: Engine oil level must be maintained
at correct level or engine damage may occur.
Refer to engine manual.
Service Performed
Each Use
Every 5 hrs.
Every 25 hrs.
Annually
Check Clutch Lever Operation •
Check Dual Handle Interlock •
Check Fasteners •
Check Clutch Cable
Adjustments *
••
Check Tire Pressure • •
Check Track Tension •
Check Engine Oil •
Change Engine Oil **
General Lubrication • •
Check Auger Gearcase Oil • •
* After first use.
** Refer to engine manual for instructions.
Description Part No.
Ariens Hi-Temp Grease
• 97 ml (3 oz) cartridges (3)
• 414 ml (14 oz) cartridge (1)
00036800
00036700
Ariens L3 Lube – 237 ml (8 oz) 00068800
Shear Bolt and Nut 53200500
Fuel Stabilizer – 118g ml (4 oz)
• Except Canada
• For Canada Only
04730400
04742500
Gearcase Seal Washer 06400920
20 Watt Headlight Bulb (Models
920026, 920027, 920028)
00432600
Spark Plug 21547400
Ariens 5W-30 Engine Oil
• 473 ml (16 oz)
• 946 ml (32 oz)
00091000
00067600
WARNING: AVOID INJURY.
Explosive separation of tire and
rim parts is possible.
• DO NOT inflate tires above
the recommended pressure.
• DO NOT inflate tires with a
compressor; use a hand
pump.
• DO NOT stand in front of tire
assembly when inflating. Use
a clip-on chuck and extension
hose long enough to allow you
to stand to one side.
• DO NOT mount a tire without
proper equipment and
experience.
