EN - 28
SPECIFICATIONS
Model Number 920025 920026 920027 920028
Description Classic 24 Compact 20 Compact 24
Compact 24
Track
Engine
Ariens
AX208 120V
Ariens AX223 120V/60W
Gross Torque* – N•m (lb-ft) 12.9 (9.5) 13.6 (10.0)
Displacement – cm
3
(in
3
)
208.0 (12.7) 223.0 (13.6)
Maximum RPM – No load 3600 ± 100
Electric Start 120V
Fuel Tank Capacity – liter (qt) 1.4 (1.5)
Headlight N/A 20 Watt
Chute
Chute Rotation Angle 205°
Rotation Control 2.5X Quick Turn
Deflector Control In-dash Lever
Auger
Snow Clearing Width – cm (in) 61.0 (24.0) 50.8 (20.0) 61.0 (24.0) 61.0 (24.0)
Gearcase Aluminum Cast Iron Cast Iron Cast Iron
Auger Diameter – cm (in) 27.9 (11.0)
Impeller
Impeller Diameter – cm (in) 30.5 (12.0)
Impeller Speed – RPM 1190
Impeller Tip Speed – m/sec (ft/sec) 19.0 (62.3)
Drive
Auger HA Belt
Traction
Disc-O-Matic
®
Speeds 6 Forward and 2 Reverse
Axle Control Pin-Lock Pin-Lock Pin-Lock Solid Axle
Tires
Size – in 13 x 4.10-6
Polar Track
15 x 5.00-6
Directional
15 x 5.00-6
Directional
N/A
Rubber Track Size – cm (in)
N/A N/A N/A
14.0 (5.5)
Wide
Directional
Track
Pressure See tire
sidewall.
See tire
sidewall.
See tire
sidewall.
N/A
Size and Weight
Length – cm (in) 138.2 (54.4) 135.4 (53.3)
Height – cm (in) 109.0 (42.9) 111.8 (44.0) 111.8 (44.0) 110.2 (43.4)
Width – cm (in) 67.1 (26.4) 56.9 (22.4) 67.1 (26.4) 67.1 (26.4)
Weight – kg (lb) 78.6 (173.3) 82.1 (181.1) 83.1 (183.1) 99.8 (220.0)
*Engine output stated in gross torque per SAE J1940 as rated by engine manufacturer.
