EN - 13
For easier right turns:
1. Remove lock pin from right wheel hub.
2. Insert lock pin through outer axle hole.
For easier left turns:
1. Remove lock pin from left wheel hub.
2. Insert lock pin through outer axle hole.
Clear a Clogged Discharge Chute
1. Stop engine, remove key and wait for all
moving parts to stop and for hot parts to
cool.
2. Use the snow clean-out tool to clear the
clog.
3. Return the tool to its storage position on
the auger housing.
STOP THE ENGINE
1. Release traction drive clutch lever.
2. Run auger / impeller for a few minutes to
remove loose or melting snow to prevent
impeller from freezing.
3. Release attachment clutch lever.
4. Turn engine key to stop position and
remove key.
5. Turn fuel valve to off position.
TRANSPORT UNIT
1. Stop engine, remove key and close fuel
valve.
2. Secure unit chassis to transport vehicle.
NOTICE: NEVER secure from rods or
linkages that could be damaged.
Your Ariens dealer can provide service and
adjustments to keep your unit operating at
peak efficiency. Contact an authorized engine
manufacturer’s service center for engine
service.
SERVICE POSITION
See Figure 15.
CAUTION: One wheel MUST be
locked with axle at all times.
WARNING: NEVER use your
hand to clean out discharge
chute.
Figure 14
Wheel Spins
Freely
Wheel Locked for
Traction
MAINTENANCE
WARNING: Read and
understand the Safety section
before proceeding.
WARNING: AVOID INJURY.
Before tipping unit, close fuel
valve and drain fuel from tank
and fuel system. (Refer to
engine manual for instructions.)
Make sure unit is secure and will
not tip.
