Installation manual for the CD72/95/15003 Page 29
SPECIFICATIONS
FUSES
CD7203 CD9503/15003
230 V fuse 315 mA 20x5
F1 Battery 2 A 20x5
F2 Auxiliary power 1 A 20x5
F3 Internal siren 1 A 20x5
F4 External siren 1 A 20x5
F5 Dialler 1 A 20x5
F6 Remotes 1 A 20x5
230 V fuse 315 mA 20x5
F1 Dialler 800 mA 20x5
F2 Output 8 800 mA 20x5
F3 Auxiliary power 1 A 20x5
F4 Battery 3,15 A 20x5
F5 External siren 800 mA 20x5
F6 Internal siren 800 mA 20x5
F7 Remotes 800 mA 20x5
F8 Expander output 800 mA 20x5
230 VAC
Battery
secondary fuse 315 mA
12 Vdc, 16 Ah maximum for CD 7203
12 Vdc, 24 Ah maximum for CD 9503/15003
Max. power output
Power consumption
CD 7203
CD 9503/15003
CD 3008/3009
CD 3048/3049
CD 9031
RD 6203
max. 1.0 A, including remotes, dialler and unit for CD7203
max. 2.0 A, including remotes, dialler and unit for CD9503/15003
typ. max.
66 mA
117 mA
26 mA 52 mA
30 mA 55 mA
26 mA
45 mA 95 mA
End of line resistors
4k7, 2 %, 0.25W
1 resistor for Alarm loop
2 resistors for Dual loop
Data bus
A
B
C
D
+ 12V
GND
Data in (to panel)
Data out (from panel)
Distance for data bus
Max 1500m.
